KeyTec® TR-FRET Human CD40 / CD40L Binding Assay kit
Size:
Price: $ Inquire
CAT.: A1090011D
The KeyTec® TR-FRET Human CD40/CD40L Binding Assay Kit can be used to measure the interaction between CD40 and CD40L proteins. This kit employs KeyTec® TR-FRET technology and is suitable for high-throughput screening of small-molecule inhibitors, peptides, or antibody blockers, offering simplicity, speed, and high accuracy.
The basic principle of this method is shown in the figure below. KeyTec® TR-FRET Solar Eu1-conjugated Streptavidin (hereafter abbreviated as SA) specifically recognizes biotinylated Human CD40 protein (AVI-Biotin), while KeyTec® TR-FRET LA2-conjugated anti-Tag1 specific antibody specifically recognizes Tag1-tagged Human CD40L protein. When CD40 binds to CD40L, the tag antibodies or affinity reagents conjugated with Solar Eu and LA, respectively, come into proximity; upon excitation by an external light source, resonance energy transfer occurs between the donor and acceptor. Measuring the signal intensity at a specific wavelength (665 nm) allows determination of the extent of interaction between CD40 and CD40L proteins. Therefore, compounds, peptides, or antibodies that block the CD40-CD40L interaction will reduce the TR-FRET signal.
| CAT. | Description | Size |
| A1090011D | KeyTec® TR-FRET Human CD40 / CD40L Binding Assay kit | 100 tests |
|
• 1 vial of 10 µL CD40 / CD40L binding Standard • 1 vial （5 μL/vial） Streptavidin - Solar Eu • 1 vial （5 μL/vial）mAb anti-Tag1 - LA • 1 vial （8 μL/vial）Biotin- CD40 • 1 vial （8 μL/vial）Tag1- CD40L • 2 vials （2 mL/vial）Binding Assay Diluent Buffer • 1 vial （2 mL/vial）Solar Eu Detection Buffer |
||
| Certificate of Analysis | Limitations | Storage Conditions |
| LOT. | For research use only |
-60℃ or below |
The KeyTec® TR-FRET Human CD40/CD40L Binding Assay Kit can be used to measure the interaction between CD40 and CD40L proteins. This kit employs KeyTec® TR-FRET technology and is suitable for high-throughput screening of small-molecule inhibitors, peptides, or antibody blockers, offering simplicity, speed, and high accuracy.
The basic principle of this method is shown in the figure below. KeyTec® TR-FRET Solar Eu1-conjugated Streptavidin (hereafter abbreviated as SA) specifically recognizes biotinylated Human CD40 protein (AVI-Biotin), while KeyTec® TR-FRET LA2-conjugated anti-Tag1 specific antibody specifically recognizes Tag1-tagged Human CD40L protein. When CD40 binds to CD40L, the tag antibodies or affinity reagents conjugated with Solar Eu and LA, respectively, come into proximity; upon excitation by an external light source, resonance energy transfer occurs between the donor and acceptor. Measuring the signal intensity at a specific wavelength (665 nm) allows determination of the extent of interaction between CD40 and CD40L proteins. Therefore, compounds, peptides, or antibodies that block the CD40-CD40L interaction will reduce the TR-FRET signal.
| CAT. | Description | Size |
| A1090011S | KeyTec® TR-FRET Human CD40 / CD40L Binding Assay kit | 500 tests |
|
• 1 vial of 25 µL CD40 / CD40L binding Standard • 1 vial （25 μL/vial）Streptavidin - Solar Eu • 1 vial （25 μL/vial）mAb anti-Tag1 - LA • 1 vial （40 μL/vial）Biotin- CD40 • 1 vial （40 μL/vial）Tag1- CD40L • 1 bottle （50 mL/bottle）Binding Assay Diluent Buffer • 1 bottle （30 mL/bottle）Solar Eu Detection Buffer |
||
| Certificate of Analysis | Limitations | Storage Conditions |
| LOT. | For research use only |
-60℃ or below |
The KeyTec® TR-FRET Human CD40/CD40L Binding Assay Kit can be used to measure the interaction between CD40 and CD40L proteins. This kit employs KeyTec® TR-FRET technology and is suitable for high-throughput screening of small-molecule inhibitors, peptides, or antibody blockers, offering simplicity, speed, and high accuracy.
The basic principle of this method is shown in the figure below. KeyTec® TR-FRET Solar Eu1-conjugated Streptavidin (hereafter abbreviated as SA) specifically recognizes biotinylated Human CD40 protein (AVI-Biotin), while KeyTec® TR-FRET LA2-conjugated anti-Tag1 specific antibody specifically recognizes Tag1-tagged Human CD40L protein. When CD40 binds to CD40L, the tag antibodies or affinity reagents conjugated with Solar Eu and LA, respectively, come into proximity; upon excitation by an external light source, resonance energy transfer occurs between the donor and acceptor. Measuring the signal intensity at a specific wavelength (665 nm) allows determination of the extent of interaction between CD40 and CD40L proteins. Therefore, compounds, peptides, or antibodies that block the CD40-CD40L interaction will reduce the TR-FRET signal.
| CAT. | Description | Size |
| A1090011L | KeyTec® TR-FRET Human CD40 / CD40L Binding Assay kit | 5,000 tests |
|
• 2 vials of 25 µL CD40 / CD40L binding Standard • 1 vial （250 μL/vial）Streptavidin - Solar Eu • 1 vial （250 μL/vial）mAb anti-Tag1 - LA • 1 vial （400 μL/vial）Biotin- CD40 • 1 vial （400 μL/vial）Tag1- CD40L • 1 bottle （200 mL/bottle）Binding Assay Diluent Buffer • 1 bottle （120 mL/bottle）Solar Eu Detection Buffer |
||
| Certificate of Analysis | Limitations | Storage Conditions |
| LOT. | For research use only |
-60℃ or below |
